Building a machine learning model is only half the battle. Deploying the model into a production environment where it can be used to make predictions is equally important. In this article, we will explore the steps involved in deploying a machine-learning model from a Jupyter Notebook to the cloud.

Photo by Safar Safarov on Unsplash

Machine learning has become an essential tool for businesses and organizations to make data-driven decisions. However, building a machine learning model is only half the battle. Deploying the model into a production environment where it can be used to make predictions is equally important. In this article, we will explore the steps involved in deploying a machine learning model from a Jupyter Notebook to the cloud.

Developing the Model

The first step in deploying a machine learning model is to develop the model itself. This is typically done in a Jupyter Notebook, where data scientists can test various modeling strategies and fine-tune the model’s parameters. Once the model is developed and tested, it’s time to move on to the next step.

Migrating the Code

The second step in deploying a machine learning model is to migrate the code from the Jupyter Notebook into executable modules. The idea here is to have a way to automate the whole model-building and prediction process, which cannot be done on Jupyter. This involves creating preprocess, train, and inference Python scripts.

Example: Preprocessing script using scikit-learn pipelines

# Example of a preprocess script using scikit-learn pipelines
from sklearn.pipeline import Pipeline
from sklearn.impute import SimpleImputer
from sklearn.preprocessing import StandardScaler

preprocess_pipeline = Pipeline([
    ('imputer', SimpleImputer(strategy='median')),
    ('scaler', StandardScaler())
])

preprocessed_data = preprocess_pipeline.fit_transform(data)

Example: Train script using scikit-learn pipelines

# Example of a train script using scikit-learn pipelines
from sklearn.pipeline import Pipeline
from sklearn.ensemble import RandomForestClassifier

train_pipeline = Pipeline([
    ('preprocess', preprocess_pipeline),
    ('classifier', RandomForestClassifier())
])

trained_model = train_pipeline.fit(X_train, y_train)

Example: Inference script using the saved pipeline

# Example of an inference script
def predict(model, data):
    # Model prediction code here
    preprocessed_data = preprocess_pipeline.transform(data)
    prediction = model.predict(preprocessed_data)
    return prediction

Saving the Model Pipelines

It is important to save the model pipelines after they have been trained. This is because the pipelines contain the preprocessing steps and the trained model, which are required for making predictions on new data. Saving the pipelines also allows for easy re-usability of the model in other applications.

Example: Saving a model pipeline using JobLib

# Example of saving the trained model pipeline
import joblib

joblib.dump(train_pipeline, 'trained_model_pipeline.joblib')

Example: Loading a saved model pipeline using JobLib

# Example of loading the trained model pipeline
import joblib

trained_model_pipeline = joblib.load('trained_model_pipeline.joblib')

Building an API

The third step in deploying a machine learning model is to build an API that will take real-time inputs, usually in the form of JSON. This API could be user-facing, such as a mobile or web app, or an internal API that connects to another application to fetch the data.

Example: Building a Flask API Endpoint

# Example of a Flask API endpoint
@app.route('/predict', methods=['POST'])
def predict():
    data = request.get_json()
    prediction = predict(trained_model, data)
    return jsonify(prediction.tolist())

Building a Model Prediction Endpoint

The fourth step in deploying a machine learning model is to build a model prediction endpoint on the API that invokes the model’s prediction API, something like the common .predict() or .generate() methods. The way the prediction works is when the input hits the /predict API (prediction endpoint), the inputs are passed to the model, and the API retrieves the model prediction (also usually in the form of JSON) like this: {id: 0001, prediction_score: 55}.

Example: Building a model prediction endpoint

# Example of a model prediction endpoint
class ModelPredictionEndpoint:
    def __init__(self, model):
        self.model = model

    def predict(self, data):
        preprocessed_data = preprocess_pipeline.transform(data)
        prediction = self.model.predict(preprocessed_data)
        return prediction.tolist()

Wrapping the API

The fifth step in deploying a machine learning model is to wrap the API using a container service like Docker so that the code is agnostic to the environment. This ensures that the API can be deployed on any platform without any issues.

Example: Creating a dockerfile for wrapping the API Endpoint

FROM python:3.8-slim-buster
WORKDIR /app
COPY requirements.txt .
RUN pip install --no-cache-dir -r requirements.txt
COPY . .
CMD ["python", "app.py"]

Docker and Kubernetes

Docker and Kubernetes are two popular tools used for deploying machine learning models to the cloud. Docker is a containerization platform that allows developers to package their applications and dependencies into a single container that can be run on any platform. Kubernetes is an open-source container orchestration platform that automates the deployment, scaling, and management of containerized applications.

Using Docker and Kubernetes one can simplify the deployment process and make it more scalable. Instead of deploying the application on a single server, Docker and Kubernetes allow for the deployment of multiple instances of the application, which can be scaled up or down based on demand.

Example: Creating a Kubernetes deployment file for wrapping the API Endpoint

# Example of a Kubernetes deployment file for a machine learning model
apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-app
spec:
  replicas: 3
  selector:
    matchLabels:
      app: my-app
  template:
    metadata:
      labels:
        app: my-app
    spec:
      containers:
      - name: my-app
        image: my-registry/my-app:latest
        ports:
        - containerPort: 5000

Deploying to the Cloud

With the model API container, you can now push this same API to any cloud provider and their service offerings: AWS EC2, Sagemaker, Beanstalk, GCP Vertex AI, App Engine. Here’s an example of deploying the Docker container on AWS Elastic Beanstalk:

  1. Create an Elastic Beanstalk environment with a Docker platform.
  2. Upload the Docker image to a container registry like Docker Hub or Amazon ECR.
  3. Configure the Elastic Beanstalk environment to use the Docker image.
  4. Deploy the application to the Elastic Beanstalk environment.

Example: Deploying the Docker container on AWS Elastic Beanstalk

# Example of deploying the Docker container on AWS Elastic Beanstalk
# Build the Docker image
docker build -t my-app .

# Tag the Docker image
docker tag my-app:latest my-registry/my-app:latest

# Push the Docker image to the container registry
docker push my-registry/my-app:latest

# Create an Elastic Beanstalk environment with a Docker platform
eb create my-environment --platform "Docker 20.10.7"

# Configure the Elastic Beanstalk environment to use the Docker image
eb setenv DOCKER_IMAGE=my-registry/my-app:latest

# Deploy the application to the Elastic Beanstalk environment
eb deploy

Conclusion

In conclusion, deploying a machine learning model to the cloud involves several steps, including developing the model, migrating the code, building an API, building a model prediction endpoint, wrapping the API using a container service like Docker, and deploying it to the cloud. Saving the model pipelines and using Docker and Kubernetes can simplify the deployment process and make it more scalable.
