Game Development in Rust: Making a Strategy Game (Part 3 — Adding Different Unit Types)

In Part 2, we added our first unit and repurposed our codebase enough to keep adding more features

Photo by orva studio on Unsplash

This article is a direct continuation of the previous one. We will add a couple of different units for each player, positioning them on opposite sides of the battlefield.

Game Development In Rust: Making A Strategy Game (Part 3 — Adding Different Unit Types)

Adding multiple units follows the same principle as adding a single one. We will build on top of our shiny create_units_system to delight our eyes with something that finally looks like a strategy game.

Adding More Units

The time to fill our battlefield with cool units has arrived. I will add the ones I like and ensure some variety, but feel free to experiment and come up with your dream teams.

Since this will be a two-player game, we need two different teams. I will pick blue units for player 1 and red ones for player 2.

We can start by adding a second type of unit. I like wizards, so I’ll go for the one in Sprite Sheets/Wizard/Wizard_Blue3.png. The code to load it is very similar to the code for the archer.

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    ...

    let wizard_blue_dark_handle = asset_server.load("Sprite Sheets/Wizard/Wizard_Blue3.png");
    let wizard_atlas = TextureAtlas::from_grid(
        wizard_blue_dark_handle,
        Vec2::new(SPRITE_SIZE, SPRITE_SIZE),
        NUM_COLUMNS,
        NUM_ROWS,
        None,
        None,
    );
    let wizard_atlas_handle = texture_atlases.add(wizard_atlas);

    commands.spawn(SpriteSheetBundle {
        texture_atlas: wizard_atlas_handle,
        sprite: TextureAtlasSprite::new(0),
        transform: Transform {
            translation: battlefield.to_battlefield_coordinates(
                2.0 * SPRITE_SIZE + SPRITE_SIZE / 4.0,
                1.0 * SPRITE_SIZE + SPRITE_SIZE / 4.0,
                1.0,
            ),
            ..default()
        },
        ..default()
    });
}

If we compile and run, we should see the new unit.

Game Development In Rust — Wizard
Game Development In Rust — Wizard

Units Housekeeping

I am delighted that now we can render multiple units. The problem is that there is a lot of repetition, and I’m not looking forward to having an unnecessarily lengthy create_units_system function. I’m not a fan of premature abstraction, and I typically like at least 3-4 occurrences of the duplicated code before I tackle it, but I think we are safe if we go ahead as the issue is clear at this point.

There are various degrees of complexity that we could go for to load a unit:

  • We could have a file with the sprite sheet file path, the position, and the sprite index.
  • We could have a function that takes these parameters.
  • A few shades in between that I won’t discuss here.

For simplicity and to avoid loading more files, I’ll go with the second option and create a function to add a unit given the sprite sheet file path, the position, and the sprite index. All the sprite sheets look the same so we can reuse the same offsets and paddings. The different sprites for the animations and directions are also standard across all units (the artist did a great job in this regard). The only difference between loading an archer and loading a wizard is the name of the sprite sheet.

I would prefer to have two functions instead of one:

  • One function to load the sprite sheet
  • Another function to spawn the unit

The reason for this is that we need the following:

  • Battlefield resource
  • Commands
  • Asset server
  • Texture atlases
  • The (column, row) where the unit will be placed on the battlefield
  • Probably a few more things I’m overlooking

That’s a lot of parameters for a single function. So, for now, I’ll split it in two, even if there is still a bit of repetition.

Let’s create the first function, called load_unit, with the following signature:

fn load_unit(
    sprite_sheet: &str,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) -> Handle<TextureAtlas> {
}

We can move all the constants inside this function together with the code to get the atlas handle for the archer and rename variables to have generic names.

fn load_unit(
    sprite_sheet: &str,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) -> Handle<TextureAtlas> {
    const SPRITE_SIZE: f32 = 32.0;
    const NUM_COLUMNS: usize = 4;
    const NUM_ROWS: usize = 4;

    let sprite_handle = asset_server.load(sprite_sheet);
    let texture_atlas = TextureAtlas::from_grid(
        sprite_handle,
        Vec2::new(SPRITE_SIZE, SPRITE_SIZE),
        NUM_COLUMNS,
        NUM_ROWS,
        None,
        None,
    );
    return texture_atlases.add(texture_atlas);
}

For now, we need to leave SPRITE_SIZE, as it is used by commands.spawn. We will tackle this shortly.

We can call our new function for the archer and the wizard.

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    const SPRITE_SIZE: f32 = 32.0;

    let archer_blue_light_atlas_handle = load_unit(
        "Sprite Sheets/Archer/Archer_Blue1.png",
        asset_server,
        texture_atlases,
    );
    ...
    let wizard_blue_dark_atlas_handle = load_unit(
        "Sprite Sheets/Wizard/Wizard_Blue3.png",
        asset_server,
        texture_atlases,
    );

    ...
}

If we try to compile this code, we will get an error when we load the wizard.

error[E0382]: use of moved value: asset_server
   --> src/main.rs:331:9
    |
304 |     asset_server: Res<AssetServer>,
    |     ------------ move occurs because asset_server has type `bevy::prelude::Res<'_, bevy::prelude::AssetServer>`, which does not implement the `Copy` trait
...
311 |         asset_server,
    |         ------------ value moved here
...
331 |         asset_server,
    |         ^^^^^^^^^^^^ value used here after move
    |
note: consider changing this parameter type in function load_unit to borrow instead if owning the value isn't necessary

   --> src/main.rs:279:19
    |
277 | fn load_unit(
    |    --------- in this function
278 |     sprite_sheet: &str,
279 |     asset_server: Res<AssetServer>,
    |                   ^^^^^^^^^^^^^^^^ this parameter takes ownership of the value error[E0382]: use of moved value: `texture_atlases`

--> src/main.rs:332:9
    |
305 |     mut texture_atlases: ResMut<Assets<TextureAtlas>>,
    |     ------------------- move occurs because `texture_atlases` has type `bevy::prelude::ResMut<'_, bevy::prelude::Assets<bevy::prelude::TextureAtlas>>`, which does not implement the `Copy` trait
...
312 |         texture_atlases,
    |         --------------- value moved here
...
332 |         texture_atlases,
    |         ^^^^^^^^^^^^^^^ value used here after move
    |
note: consider changing this parameter type in function `load_unit` to borrow instead if owning the value isn't necessary
   --> src/main.rs:280:26
    |
277 | fn load_unit(
    |    --------- in this function
...
280 |     mut texture_atlases: ResMut<Assets<TextureAtlas>>,
    |                          ^^^^^^^^^^^^^^^^^^^^^^^^^^^^ this parameter takes ownership of the value

Both asset_server and texture_atlases are moved when we load the archer, so they can’t be used when we load the wizard.

One way of fixing this issue is to declare these parameters as references:

fn load_unit(
    sprite_sheet: &str,
    asset_server: &Res<AssetServer>,
    mut texture_atlases: &ResMut<Assets<TextureAtlas>>,
) -> Handle<TextureAtlas> {
   ...
}

We must also pass the variables as references when we call the function.

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    const SPRITE_SIZE: f32 = 32.0;

    let archer_blue_light_atlas_handle = load_unit(
        "Sprite Sheets/Archer/Archer_Blue1.png",
        &asset_server,
        &texture_atlases,
    );

    ...

    let wizard_blue_dark_atlas_handle = load_unit(
        "Sprite Sheets/Wizard/Wizard_Blue3.png",
        &asset_server,
        &texture_atlases,
    );

    ...
}

But this still doesn’t work. We get an error when returning the atlas handle.

error[E0596]: cannot borrow *texture_atlases as mutable, as it is behind a & reference

--> src/main.rs:298:12
    |
280 |     texture_atlases: &ResMut<Assets<TextureAtlas>>,
    |                      ----------------------------- help: consider changing this to be a mutable reference: `&mut bevy::prelude::ResMut<'_, bevy::prelude::Assets<bevy::prelude::TextureAtlas>>`
...
298 |     return texture_atlases.add(texture_atlas);
    |            ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^ `texture_atlases` is a `&` reference, so the data it refers to cannot be borrowed as mutable

Well, no one said it’d be easy 🙂.

The Rust compiler is telling us that it can’t borrow the reference to texture_atlas as mutable. We can fix this problem by changing the parameter from & to &mut.

fn load_unit(
    sprite_sheet: &str,
    asset_server: &Res<AssetServer>,
    mut texture_atlases: &mut ResMut<Assets<TextureAtlas>>,
) -> Handle<TextureAtlas> {
   ...
}

We must also change the calls to this function to pass mutable references.

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    const SPRITE_SIZE: f32 = 32.0;

    let archer_blue_light_atlas_handle = load_unit(
        "Sprite Sheets/Archer/Archer_Blue1.png",
        &asset_server,
        &mut texture_atlases,
    );

    ...

    let wizard_blue_dark_atlas_handle = load_unit(
        "Sprite Sheets/Wizard/Wizard_Blue3.png",
        &asset_server,
        &mut texture_atlases,
    );

    ...
}

Our code finally compiles and runs without any issues.

The above was a bit of hard work, but worth it. When we have 8–12 units, we will be glad we are not copying and pasting the same code repeatedly. This is the diff for the refactoring so far.

The next step is to do something similar for spawning a unit. We are going to need a function with the following signature:

fn spawn_unit(
    atlas_handle: Handle<TextureAtlas>,
    column_in_battlefield: usize,
    row_in_battlefield: usize,
    battlefield: Res<Battlefield>,
    mut commands: Commands,
) {
    ...
}

We are passing the atlas handle, the position on the battlefield, and the battlefield itself so it can transform the coordinates. We also need the commands instance to span the unit sprite.

The function body looks like this:

fn spawn_unit(
    atlas_handle: Handle<TextureAtlas>,
    column_in_battlefield: usize,
    row_in_battlefield: usize,
    battlefield: Res<Battlefield>,
    mut commands: Commands,
) {
    const SPRITE_SIZE: f32 = 32.0;

    commands.spawn(SpriteSheetBundle {
        texture_atlas: atlas_handle,
        sprite: TextureAtlasSprite::new(0),
        transform: Transform {
            translation: battlefield.to_battlefield_coordinates(
                column_in_battlefield as f32 * SPRITE_SIZE + SPRITE_SIZE / 4.0,
                row_in_battlefield as f32 * SPRITE_SIZE + SPRITE_SIZE / 4.0,
                1.0,
            ),
            ..default()
        },
        ..default()
    });
}

And we can replace the code in the system:

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    let archer_blue_light_atlas_handle = load_unit(
        "Sprite Sheets/Archer/Archer_Blue1.png",
        &asset_server,
        &mut texture_atlases,
    );
    spawn_unit(archer_blue_light_atlas_handle, 0, 0, battlefield, commands);

    let wizard_blue_dark_atlas_handle = load_unit(
        "Sprite Sheets/Wizard/Wizard_Blue3.png",
        &asset_server,
        &mut texture_atlases,
    );
    spawn_unit(wizard_blue_dark_atlas_handle, 2, 1, battlefield, commands);
}

We have a similar problem with battlefield and commands being moved during the first function call, so we need to declare them as references.

fn spawn_unit(
    atlas_handle: Handle<TextureAtlas>,
    column_in_battlefield: usize,
    row_in_battlefield: usize,
    battlefield: &Res<Battlefield>,
    commands: &mut Commands,
) {
    ...
}
fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    let archer_blue_light_atlas_handle = load_unit(
        "Sprite Sheets/Archer/Archer_Blue1.png",
        &asset_server,
        &mut texture_atlases,
    );
    spawn_unit(
        archer_blue_light_atlas_handle,
        0,
        0,
        &battlefield,
        &mut commands,
    );

    let wizard_blue_dark_atlas_handle = load_unit(
        "Sprite Sheets/Wizard/Wizard_Blue3.png",
        &asset_server,
        &mut texture_atlases,
    );
    spawn_unit(
        wizard_blue_dark_atlas_handle,
        2,
        1,
        &battlefield,
        &mut commands,
    );
}

Our code should now compile and run correctly.

One more optional thing we can do to make the code in the system more concise is to inline the atlas handles:

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    spawn_unit(
        load_unit(
            "Sprite Sheets/Archer/Archer_Blue1.png",
            &asset_server,
            &mut texture_atlases,
        ),
        0,
        20,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/Wizard/Wizard_Blue3.png",
            &asset_server,
            &mut texture_atlases,
        ),
        2,
        1,
        &battlefield,
        &mut commands,
    );
}

I find this way more declarative, decreasing the chances of using the wrong variable. Rust would catch some of these mistakes, but I still like reducing the human error variable as much as possible. But this is a matter of taste and style for the most part.

Note that we are duplicating SPRITE_SIZE. There are already quite a few parameters being passed into spawn_unit, so I would rather duplicate it than clutter the function signature even more. We could also move it as a global constant, especially since we might move create_units_system and its related functions into its own module, making this variable global to only that file.

I don’t like global constants, and I’d rather duplicate it as long as it’s only in two functions (I would probably do this if all the code related to units was in a separate module instead of in the main file). Or we could assume that all the sprites will have the same size as one tile and move this knowledge into the battlefield. YMMV.

We could have chosen not to pass commands into spawn_unit, and return the SpriteSheeBundle instead, removing one parameter from the list. But I wanted the function to actually spawn the unit.

We could also have passed the number of columns and rows into spawn_unit as a tuple, saving one parameter. I’m not a fan of tuples as they are less readable than separate variables or structs. We could have also created a struct, but I thought that would be overkill.

There are many ways of designing these implementation details, and you might have different preferences. I might look at this code in two weeks and want to adjust. For now, I’m happy enough. But feel free to implement your preferred variations if needed.

Here is the diff for this section.

Building the Teams

After all this hard work, it’s time to enjoy the rewards and populate our battlefield. Go wild and add all sorts of units. Our battlefield is getting a bit small to host 32×32 sprites. We will fix this later. These are the units I added for now:

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    spawn_unit(
        load_unit(
            "Sprite Sheets/Archer/Archer_Blue1.png",
            &asset_server,
            &mut texture_atlases,
        ),
        0,
        0,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/Wizard/Wizard_Blue3.png",
            &asset_server,
            &mut texture_atlases,
        ),
        1,
        1,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/LanceKnight/LanceKnight_Blue.png",
            &asset_server,
            &mut texture_atlases,
        ),
        2,
        2,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/SwordFighter/SwordFighter_LongHair_Blue1.png",
            &asset_server,
            &mut texture_atlases,
        ),
        2,
        0,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/Archer/Archer_Red1.png",
            &asset_server,
            &mut texture_atlases,
        ),
        5,
        1,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/Wizard/Wizard_Red3.png",
            &asset_server,
            &mut texture_atlases,
        ),
        5,
        0,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/LanceKnight/LanceKnight_Red.png",
            &asset_server,
            &mut texture_atlases,
        ),
        4,
        2,
        &battlefield,
        &mut commands,
    );

    spawn_unit(
        load_unit(
            "Sprite Sheets/SwordFighter/SwordFighter_LongHair_Red1.png",
            &asset_server,
            &mut texture_atlases,
        ),
        3,
        1,
        &battlefield,
        &mut commands,
    );
}

If we compile and run, we’ll see that the red sprites are not facing the blue ones, which is unfortunate.

We need to flip the red sprites. This is done by specifying the rotation attribute in the transform inside the SpriteBundleSheet:

  • We need to rotate the sprites 180 degrees, which is the same as PI radians.
  • We need a flag to flip only the red sprites.

In spawn_unit, we can add a flip boolean and set the rotation to either default or PI radians for the y axis.

Strategy Game: Red team, but not quite right
Strategy Game: Red team, but not quite right
fn spawn_unit(
    atlas_handle: Handle<TextureAtlas>,
    column_in_battlefield: usize,
    row_in_battlefield: usize,
    flip: bool,
    battlefield: &Res<Battlefield>,
    commands: &mut Commands,
) {
    const SPRITE_SIZE: f32 = 32.0;

    commands.spawn(SpriteSheetBundle {
        texture_atlas: atlas_handle,
        sprite: TextureAtlasSprite::new(0),
        transform: Transform {
            translation: battlefield.to_battlefield_coordinates(
                column_in_battlefield as f32 * SPRITE_SIZE + SPRITE_SIZE / 4.0,
                row_in_battlefield as f32 * SPRITE_SIZE + SPRITE_SIZE / 4.0,
                1.0,
            ),
            rotation: if flip {
                Quat::from_rotation_y(std::f32::consts::PI)
            } else {
                Quat::default()
            },
            ..default()
        },
        ..default()
    });
}

We need to pass either false or true, depending on the sprite.

fn create_units_system(
    battlefield: Res<Battlefield>,
    mut commands: Commands,
    asset_server: Res<AssetServer>,
    mut texture_atlases: ResMut<Assets<TextureAtlas>>,
) {
    spawn_unit(
        load_unit(
            "Sprite Sheets/Archer/Archer_Blue1.png",
            &asset_server,
            &mut texture_atlases,
        ),
        0,
        0,
        false,
        &battlefield,
        &mut commands,
    );

    ...

    spawn_unit(
        load_unit(
            "Sprite Sheets/Archer/Archer_Red1.png",
            &asset_server,
            &mut texture_atlases,
        ),
        5,
        1,
        true,
        &battlefield,
        &mut commands,
    );

    ...
}

And so on.

If we run our game, the issue should be fixed.

Strategy Game: Teams ready for the battle
Strategy Game: Teams ready for the battle

You can find the last diff here and the code for this chapter.

Conclusion

Our game is starting to look like an actual strategy game, except for the lack of actual interaction from the player.

We will start solving this little “inconvenience” in a later article, where we will add a way to move units. I hope you are looking forward to it as much as I am!

Thank you for reading.

This article was originally published on my blog.

Game Development in Rust: Making a Strategy Game (Part 3 — Adding Different Unit Types) was originally published in Better Programming on Medium, where people are continuing the conversation by highlighting and responding to this story.

Previous Post
Next Post
